specialized printer, for post offices, banking, administration

Olivetti PR2 Plus

Olivetti PR2 Plus Olivetti PR2 Plus is a specialized printer, which is most often used for banking and post office applications as well as in public administration, health services, travel industry, casinos, lotteries and others.
    Main features:
  1. high reliability and extremely user friendly
  2. ultra fast auto alignment for the best performance
  3. superior printing speeds: up to 560 CHAR/SEC in VHSD
  4. one of the smallest and quietest models in its product class
  5. new ink ribbon prints up to 10 million characters
  6. management of all bank forms ultra-fast alignment for improved performance
  7. optional dual-side color scanning and magnetic-stripe reading and writing
  8. capable to print on single-sheet and multiple-copy documents and on passbooks
 OLIVETTI PR2 Plus [250 KB] - PDF format

Specification
Technology 24-pin dot matrix
Resolution 240 x 360 dpi
Printing speed at 10 cpi VHSD: 560 cps; HSD: 510 cps; Draft: 370 cps; NLQ: 185 cps; LQ: 125 cps; BIM: 2000 dps
Pitch 10, 12, 15, 16,6, 17,1 cpi
Line length 238,76 mm (94 columns at 10 cpi)
Line spacing 1/5", 1/6", n/216", n/240"
Number of insertors 1
Document Insertion automatic with autoborder
Document Handling completely flat paper feed
Document Thickness automatic document-thickness monitoring
Feed width 245 mm
Number of copies original + 6 copies
Emulation Olivetti Standard, IBM PP & X24; Optional: IBM 4722/9068, IBM PP & X24 WINCOR 4915, EPSON LQ 80550, UNISYS EFP series
Interfaces Standard: USB 2.0, RS232 seriál, IEEE 1284 parallel; expansion slot for optional interface
Fonts OCR A-B, ROMAN, Sans Serif, Italic, Bar Code
Ribbon cartridge 10 million characters
Dimensions (w x d x h) 384 x 296 x 204 mm
Weight 10.5 kg
Noise level < 54 dBA (ISO 7779 with ECMA 132 text)
Voltage 220/240 V, 50/60 Hz, Built-in power supply
Power consumption printing: 85 W max, Standby: 13W
Certifications CE ISO 9001: 2000, TüV NRTL, FCC class A verified
Color Scanner - optional for all models
Technology contact type
Physical position above the paper track
Horizontal position left-hand side
Scanning area (w) 65÷210 mm, (h) 70÷297 mm
Definition 600 dpi RGB color 24 bit
Light source LED lines, RGB
Scan time Max 10" inch/sec. 3.3" full color
Connection Centronics ECP mode, USB 2.0
Embeded in some models
MICR Reader able to read MICR, CMC7 and E13B code lines
Magnetic reader able to read magnetic strips
Models
PR2 10 Plus basic model
PR2 12 Plus basic model with horizontal magnetic reader
PR2 12 MICR Plus basic model with horizontal magnetic reader and MICR reader
